Calendered aluminum foil for lithium battery positive collector
-
For lithium-ion batteries, aluminum foil is usually used as positive collector, while copper foil is used as negative collector. Firstly, copper aluminum foil has good conductivity, soft texture and low price. Secondly, copper aluminum foil is relatively stable in the air. Thirdly, the positive and negative potential of lithium-ion battery determines aluminum foil for positive electrode and copper foil for negative electrode, not vice versa.
The collector not only plays the role of carrying the active material, but also collects the electrons generated by the electrochemical reaction and leads them to the external circuit, so as to form a larger current output, so as to realize the process of chemical energy into electrical energy. In order to ensure the stability of the collector in the battery, the purity of both is required to be more than 98%.
Aluminum foil is mainly calendered aluminum foil. Aluminum foil for positive electrode has been reduced from 16um in previous years to 14um, and then to 12um. Now many battery manufacturers have mass produced 10um aluminum foil, even 8um aluminum foil.Product index parameters
No. Item Unit Production Standard Test Method 1 Alloy N/A 1060 1N00 N/A 2 Status N/A H18 H18 N/A 3 Aluminum content % ≥99.60 ≥99.60 Direct-reading spectrometer 4 Single / double-sided bright N/A Double -sided bright Double -sided bright Visual 5 Thickness um 12±5% 13±5% 15±5% 12±5% 15±5% Cut the aluminum foil into 100cm²,Standard area sample, weigh and Calculate 6 Area density g/㎡ 32.46±1.63g/㎡ 35.17±1.76g/㎡ 40.58±2.03g/㎡ 32.52±1.63g/㎡ 40.65±2.03g/㎡ Cut the aluminum foil into 100cm2,Standard area sample, weigh (denoted by W, Unit is g), the areal density is:：W*100 9 Tensile Strength MPa ≥180 ≥180 ≥180 ≥240 ≥240 Microcomputer control Electronic Universal Testing Machine 10 Extension % ≥2.0 ≥2.5 ≥2.8 ≥2.5 ≥3.0 Microcomputer control Electronic Universal Testing Machine 11 Surface wetting tension Dyne/cm ≥30 ≥30 ≥30 ≥30 ≥30 Dyne Test Pen 12 Pinhole NO./㎡ ≤20 ≤10 ≤10 ≤20 ≤10 Visual with Pinhole box 7 Width mm Tolerance：±1.0mm steel tap 8 Chips N/A inner diameter：76.2mm/3inch vernier caliper Material：Aluminum Visual 14 Appearance Quality The surface of aluminum foil should be flat and clean without obvious defects such as scratches, holes, corrosion and non-metal pressing. Aluminum foil coil should be wound, does not allow serious wrinkle, bulge, depression or bumps or other defects. 15 Packaging and Storage 1、The sealing device is in the wooden box, the wooden box cannot have the footprint and so on dirty
2、the outer packing without damage, the product has no deformation, clearly marked (manufacturer, model, batch number), 6 factory inspection report
3、When packing, the specification is required to be placed in a box, and the materials of different specifications shall not be mixed.16 Storage Conditions Sealed at Environment with Temperature of 5 ~ 45 ℃, Humidity ≤ 95% Anti-Rain, Anti-Moisture, anti-ibration 17 Shelf Life 6 Months from the Date of Shipment
Delivery Time:In Stock
Please contact AFT for the required width
